AN28-54A | BOLT, CLEVIS

INVENTORY
Part Number AN28-54A
Stock 144
Condition NEW
Manufacturer AIRFASCO
Unit of Measure EA
Packaged Amount INQUIRE
REF PC Weight (LB) 0.21
Retail Price
A web price is unavailable for this item. Please request a quote.
PLACE RFQ BELOW
Email*
Company
Quantity*
Reference #
Comment
Button
SENDING - PLEASE WAIT

Note: * Email and Quantity are required.

SPECIFICATIONS
UoM
Standard,Inches
NOMINAL HEAD THICKNESS
0.250
MAX. HEAD THICKNESS
0.266
MIN. HEAD THICKNESS
0.234
MAX. BODY DIAMETER
0.497
MIN. BODY DIAMETER
0.495
NOMINAL GRIP LENGTH
3.000
MAX. GRIP LENGTH
3.016
MIN. GRIP LENGTH
2.984
NOMINAL TOTAL LENGTH
3.422
MAX. TOTAL LENGTH
3.438
MIN. TOTAL LENGTH
3.406
MATERIAL
Alloy Steel (UNS G41300 OR UNS G87400)
FINISH
CADMIUM PLATE PER AMS-QQ-P-416 TYPE II, CLASS 2
THREAD SPECS
.5000-20 UNF-3A
LOCKING MECHANISM
N/A
COMMENTS / ADDITIONAL SPECIFICATIONS
Slotted Dome Head Diameter: .875 +/- .016 | Single Shear at full dia: 14700 LBF | TENSILE: 9250 LBF
The prints & data found here within are not to be used for the manufacturer, procurement, or use of this product. They are for educational proposes only.
